1.Can be used in high divided area
2.Short circuit and the fault will be avoided in a period when cable is burned directly

Standard compiled with

GB/T12706-2002 Power cables with extruded insulation and their accessories for rated voltage from 1KV (Um =1.2KV) up to 35KV (Um =40.5KV)

IEC60502-1997 Power cable with extruded insulation and their accessories for rated voltage from 1KV up to 30KV

Service performance

1. Rated voltage:0.6/1kv

2. Cross-sectional area: (1~5)*(1.5~800mm2), 3*(1.5~500mm2) +1*(1~240mm2), 3*(1.5~500mm2) +2*(1~240mm2),4*(1.5~500mm2) +1*(1~240mm2)

3. The highest rated working temperature: 90 °C, the highest conductor short-circuit temperature: 250°C

4. Excellent electrical performance, resistance to chemical corrosion.

They can stand advisable traction when laid
Can be used in high divided area
Can stand traction from inside
Left low smoke halogen-free after burned
Retard the burning of the cable
Short circuit and the fault will be avoided in a period when cable is burned directly
Laying temperature

The laying temperature is less than 0°C.

Layout of cables

Single core cables: In parallel (spacing side by side=1D D-0verall diameter)

Multi-core cables: laid individually
